Bell-Stir Magnetic Stirrers, single & 4 Position

* Designed for mammalian and bacterial cultures
* Ideal for tissue cultures grown in spinner flasks
* Low wattage DC motors and solid state circuitry
* speed Range: 30-1000 rpm

Stock No - V/Hz/A - Max Flask (L) - Dimensions W x D x H

7760-06100 - 100/50/1.0 - 1 - 16 x 16 x 13cm
7760-06103 - 100/50/1.0 - 8 - 26 x 26 x 13cm
7760-06000 - 115/60/1.0 - 1 - 16 x 16 x 13cm
7760-06005*- 115/60/1.0 - 500ml - 26 x 26 x 13cm
7760-06003 - 115/60/1.0 - 8 - 26 x 26 x 13cm
7760-06220 - 230/50/1.0 - 1 - 16 x 16 x 13cm
7760-06223 - 230/50/1.0 - 8 - 16 x 26 x 13cm

*Four position model

Bell-ennium One Position Magnetic Stirrers

Stock No. Description (V/Hz/W/A)
7785-D1108 One Position Digital Display 100-115/50-60/1.0
7785-D1208 One Position Digital Display 230/50/1.0
7785-P1108 One Position Process Control 100-115/50-60/1.0
7785-P1208 One Position Process Control 230/50/1.0
7785-D1136 One Position Digital display 100-115/50-60/1.0
7785-D1236 One Position Digital Display 230/50/1.0
7785-11111 Optional Motion Alarm, Digital Display, Factory Install Only
7785-22222 Optional Motion Alarm, Process Control, Factory Install Only

Specifications:
Speed Range 15-500rpm
Dimensions 8L: 10 x 11 x 3,5"(25 x 28 x 8.5cm)*
36L: 18 x 20 x 3,5"(45 x 51 x 8.5cm)*
Weight 8L: 8 lbs (4.kg)
36L: 17 lbs (7.5kg)
Maximum Flask Size 8L, 36L
* Allow 1 - 2 inches for rear plug-in accessories

Bell-ennium Two Position Magnetic Stirrers

Stock No. Description (V/Hz/W/A)
7785-D1502 Two Position Digital Display 100-115/50-60/1.0
7785-D1512 Two Position Digital Display 230/50/1.0
7785-P1502 Two Position Process Control 100-115/50-60/1.0
7785-P1512 Two Position Process Control 230/50/1.0
7785-11111 Optional Motion Alarm, Digital Display, Factory Install Only
7785-22222 Optional Motion Alarm, Process Control, Factory Install Only

Specifications:
Speed Range 15-500rpm
Dimensions 20 x 11 x 3,5" (51 x 28 x 8.5cm)*
Weight 12 lbs (5.5kg)
Maximum Flask Size 2 x 8L

BTBII - Back-To-Basics II Magnetic Stirrers, 4 Position

* For light duty applications
* Speed Range: 10-190 rpm
* Maximum Flask Size: 4 x 500m
* Dimensions: 4 Position 3.5 x 10 x 10.5"(9 x 25 x 27cm)
Stock No. Description V/Hz/A
7677-50115 4 Position 115/60/1
7677-50230 4 Position 230/50-60/1
*24V in-line power supply included



Bell-ennium Five Position Magnetic Stirrers

Stock No. Description (V/Hz/W/A)
7785-D2005 Five Position Digital Display 100-115/50-60/1.0
7785-D2015 Five Position Digital Display 230/50/1.0
7785-P2005 Five Position Process Control 100-115/50-60/1.0
7785-P2015 Five Position Process Control 230/50/1.0
7785-11111 Optional Motion Alarm, Digital Display, Factory Install Only
7785-22222 Optional Motion Alarm, Process Control, Factory Install Only

Specifications
Speed Range 15-500rpm
Dimensions 16,5 x 18 x 3.5" (42 x 45 x 8.5cm)*
Weight 18 lbs (8.2kg)
Maximum Flask Size 5 x 1L or 4 x 3L
* Allow 1 - 2 inches for rear plug-in accessories

Bell-ennium Compact Five Position Magnetic Stirrers

Stock No. Description (V/Hz/W/A)
7785-D5005 Five Position Compact Digital Display 100-115/50-60/1.0
7785-D5015 Five Position Compact Digital Display 230/50/1.0
7785-P5005 Five Position Compact Process Control 100-115/50-60/1.0
7785-P5015 Five Position Compact Process Control 230/50/1.0
7785-11111 Optional Motion Alarm, Digital Display, Factory Install Only
7785-22222 Optional Motion Alarm, Process control, Factory Install Only

Specifications:
Speed Range 15-500rpm
Dimensions 14,5 x 15 x 3"(37 x 38 x 8.cm)
Weight 18 lbs (8.2kg)
Maximum Flask Size 5 x 500mL or 4 x 1L

Bell-ennium Nine Position Magnetic Stirrers

Stock No. Description (V/Hz/W/A)
7785-D9005 Nine Position Digital Display 100-115/50-60/1.0
7785-D9015 Nine Position Digital Display 230/50/1.0
100-115/50-60/1.0
7785-P9005 Nine Position Process Control 230/50/1.0
7785-P9015 Nine Position Process Control
7785-11111 Optional Motion Alarm, Digital Display, Factory Install Only
7785-22222 Optional Motion Alarm, Process Control, Factory Install Only

Specifications:
Speed Range 15-500rpm
Dimensions 16.5 x 18 x 3.5" (42 x 45 x 8.5cm)*
Weight 20 lbs (9kg)
Maximum Flask Size 9 x 500mL (70mm neck)
* Allow 1 - 2 inches for rear plug-in accessories

Accessories
Stock No. Description
9700-10115 In-line Power Supply, 100/115V
9700-10230 In-line Power Supply, 230V
