38 cu.ft. Refrigerated Roll-In Incubator

* Ideal for insect cell incubations performed at 27 Celcius
* Microprocessor PID temperature controller
* Accommodates up to 9-deck fixed frame or base + 7 modular Bellco cell production roller apparatus
* Accessory power outlets (4) in chamber provided for supplemental equipment
* Forced air circulation facilitates even temperature distribution
* Control panel w/power switch, convenience outlet, safety thermostat, refrigeration switch, temperature controller
* "Flush to Floor" design allows easy loading of Bellco Roller Apparatus

Specifications
Temperature Range 20 Celcius to 50 Celcius
Temperature Uniformity +/- 0.5 Celcius cool and +/-1.0 Celcius heat
Exterior Dimensions 41 x 32 x 87" (104 x 81 x 221 cm)
Chamber Dimensions 35 x 26 x 70" (89 x 66 x 178 cm)
Capacity 38 cu. ft. (1075L)
Refrigerant R134A, non-CFC type

Stock No. V/Hz/Watts Description
7728-01100 100/50-60/1500 Single Window Door
7728-51100 100/50-60/1500 Double Window Door
7728-01005 115/50-60/1500 Single Window Door
7728-51005 115/50-60/1500 Double Window Door
7728-01230 230/50/1500 Single Window Door
7728-51230 230/50/1500 Double Window Door

Optional Accessories
7728-40035 Stainless Steel Shelf
7728-40050 UltraVented Heavy Duty Stainless Steel Shelf
7728-80000 Temperature Alarm (factory install)
7728-35115 Temperature Chart Recorder, 115V
7728-35230 Temperature Chart Recorder, 230V

40 cu. ft. Standard Roll-In Incubator

* Accessory outlets in chamber provide power for supplemental equipment
* Optional over-temperature alarm and temperature recorder modules available
* "Flush to Floor" design allows easy loading of Bellco Roller Apparatus
* Accepts all Bellco roller apparatus (except 7630-80510/82510)
* Shelves sold separately

Stock No. V/Hz/Watts Description
7728-09100 100/50-60/1500 Door w/ Single Window
7728-09005 115/50-60/1500 Door w/ Single Window
7728-95220 230/50/1500 Door w/ Single Window
7728-59100 100/50-60/1500 Door w/ Double Window
7728-59005 115/50-60/1500 Door w/ Double Window
7728-59522 230/50/1500 Door w/ Double Window

Specifications
Temperature Range +9 Celcius ambient to 50 Celcius (+/-2 Celcius)
Temperature Uniformity* +/-1.5 Celcius
Exterior Dimensions 41 x 31 x 87" (104 x 78 x 221cm)
Chamber Dimensions 35 x 26 x 76" (89 x 66 x 193cm)
Chamber Capacity 40 cubic feet (1132L)
*tested with fully loaded 10-deck roller apparatus
